No one’s asked the question “What in the world is Ion Deposition and why do you need it for printing?”.
Let me explain. In order to understand how Ion Deposition works, you have to know a bit about how laser printers work. Briefly, a metal drum is coated with silicone so that it makes a diode between the drum and an electric charge placed evenly on the surface. The diode blocks the charge from flowing to the metal drum which can be at ground potential. When a laser is made to shine on the surface of the drum, the diode breaks down and the charge at that laser spot is bled off to ground. The toner, which is kept at the same charge potential as the unaffected regions of the drum, transfers to the areas that were discharged forming an image of the text or picture. As the drum turns, the toner is then transferred with another charge to the paper that is going through the printer. The paper continues on to a fuser which melts the toner into the paper fibers making the image. The drum is then cleaned of the excess toner and recharged in preparation for another image.
In ion deposition printers the drum is also made of an aluminum extrusion but has a much thicker wall. The drum surface is not coated with silicone but is anodized forming a layer of oxide that is very resistant to abrasion. It is treated with wax to seal any pores in the crystalline structure of the oxide layer.
The “head” which generates the ions is a laminated structure similar to a multi-layer printed circuit board. Starting off with an insulator, the metal layer is made of stainless steel and etched into parallel control tracks (16 or more) along the length of the printed circuit board which can be 15” long. Next, a mica layer of precise thickness is glued down onto the control tracks. Another layer of stainless steel is etched and deposited on top of the mica layer in the shape of small tuning forks (call them fingers) and brought out to the sides of the printed circuit board where contacts with the electronics can me made. Then another insulating layer is applied and the final stainless steel layer is glued on that has small holes at the intersection of the control tracks with the fingers (call it the grid layer). When a high voltage and high frequency AC (around 2000 V) is applied to a control line (one at a time) a corona discharge is created along the length of the control line and fingers and just below the small holes of the grid layer. The grid layer is held at a potential that prevents the ions from escaping through the holes. The electronics then biases the fingers to the same potential as the grid layer and allows the ions to project through the holes depositing them on the drum that is rotating closely to the head. The ions stick to the drum. The scanning of the control lines and the fingers is performed by the electronics to form a charge image on the drum as it rotates below the head.
The toner roll is also an aluminum cylinder that has a permanent magnet inside. A hopper holds the toner which is in a powder form above the roll. A gate shaves off the precise thickness of the toner that is held to the drum by magnetic attraction and forms a bristle-like brush. The toner particles flip many times as the aluminum drum rotates over the fixed magnet inside and encounters north and south poles. The “brush” is located almost touching the drum. When charged areas on the drum pass close to the toner brush, particles of toner are adhered to the charge. The drum then has an image of the text or picture in toner as it revolves further toward the paper.
Since the drum is very hard and impervious to abrasion, it can be used effectively to transfer the toner to the paper by cold pressure fusing. A plastic roll below the imaging drum is made to bear on it at high pressure. The paper is fed into the “nip” between the two rollers. The plastic drum (a little secret) is skewed just slightly to the center line of the imaging roller causing it to bend, like two pieces of rope twisted together and, create a uniform pressure along the contact zone. The toner is transferred and fused at the same time by the generated heat of the pressure applied and the sliding that goes on between the two rollers due to the skew. Very little toner remains on the drum. The drum is cleaned by a knife scraping the remains into a little removable bucket for cleaning. Then the drum is erased of any remaining charge by a corona discharge wire and is ready for the next image.
You might ask what are the advantages and disadvantages of the two competing technologies. Ion deposition imaging quality is slightly lower than laser due to the many sources of ion “jets” making the image. They make dots of slightly different size and deteriorate unevenly. The laser uses a single source of light for every part of the drum placing precisely the same size dot across the entire image. As the laser degrades, the image fades as a whole and is not noticeable. However, the image quality of ion deposition is still acceptable for uses where impact printers were once the only technology available. The speed of imaging far exceeds that of the laser and the simplicity of the mechanism and the robustness of the printing engine makes it a good choice in these applications. The printing head uses the same manufacturing processes used in printed circuit manufacturing and is well understood. It is made such that the user can easily replace it when the print quality degrades sufficiently usually after a hundred thousand sheets of paper have gone through the printer. The drum lasts over a million sheets. When you calculate the cost per page including all of the consumables and compare them against the laser, you find that the cost of ion deposition is one tenth the cost of the laser. This is a significant cost saving for a large volume printing company.
The engine, however, is not the complete story in making a high speed printer. You also need to feed a large quantity of cut sheet paper into it and stack the paper into a neat pile as it comes out.
What has this to do with electronics? I say don’t limit yourself to one discipline… electronics and mechanics are closely linked in industry. You must be able to speak the language of both to make it in the industrial world.
It’s time to get back on topic: electronics as a hobby.
From the time I was born in 1942 until about 1955, the only “electronics” in the house was a telephone and a tube radio. In 1955 we added a tube television (a Sylvania TV with fluorescent light surrounding the picture tube). It broke down often and I remember having to replace the picture tube and the many vacuum tubes located in the chassis. The local drug store carried all the vacuum tube types and had a self service tube tester where you could check them yourself.
I began my interest in electronics as a hobby around 1955 when I acquired a tube amplifier and a speaker in a primitive cabinet. I went to Electro Sonic (a local electronics store) and bought a simple record player turntable with an automatic changer. I connected all of these components together learning about the requirements for coaxial cable and other necessities. Very quickly afterwards the transistor took over and eventually completely eliminated the vacuum tube.
At that time in history, I was able to buy a magazine called Popular Electronics that had many DIY articles in it. I started to tinker with those construction plans and carried on building projects throughout my high-school days. I remember building a megaphone to use at football games and make my shouts heard over everyone else. At University of Toronto where I studied Electrical Engineering, we had a physics professor named John Bird (https://www.electro-tech-online.com/custompdfs/2013/07/bio_John20Bird.pdf). He was the national car rally champion having won the Canadian Winter Rally a number of times. Some of the guys and I set up a car rally of our own and got John Bird to check it out for accuracy. I surprised everyone in the class one day by bringing in a computer I had built to help my driver and I in winning the rally. It was an analog computer that had 3 rotary switches where you could enter the miles per hour you were supposed to drive to 1 decimal point (i.e. – 36.6 mph). When the computer was started, it would advance a mechanical counter every 1/10 of a mile. All the driver had to do was keep the car’s odometer in step with the counter on the computer and the car was on time. When you entered a check point with your score card, you had to be no more than +/- one minute out from the calculated time or lose a point for each minute over or under. John Bird navigated across Canada from coast to coast and only had 6 points against him. On the actual rally the computer made no difference. My driver got stuck in a snow bank that was as high as the roof of the car and we lost the rally. Cost me a case of beer on a bet that we would win.
Electronics as a hobby is nowhere near dead! You can still get DIY magazines such as Circuit Cellar and Elektor although they are heavily geared to digital electronics and microprocessors.
Why not start where it all began: vacuum tubes. A friend of mine in Florida restored an old car from the late 1940s and drove a group of us to lunch in it. He turned on the car radio and out came music from the 1940s. I was thinking at the time “What station would be playing this kind of music in this day and age”? I then figured out that my friend had made a radio transmitter and had it hidden in the trunk of the car that played pre-recorded music from that era.
One of my favorite songs is Radio Ga Ga by Queen. Radio still intrigues me since it’s like fishing for a weak signal in an environment polluted by radio noise. When you can select the signal you are interested in, it’s like having hooked a large fish on your line.
There are many articles on the Internet showing how to construct a vacuum tube radio transmitter for the AM band. Why not start with a project like that and enjoy some history in the process. You can load your iPod with old shows from an era gone by such as Abbott and Costello and The Shadow and amaze your friends when you play them on your AM radio. You can get into restoring old tube radios as a hobby. Check out the Internet. There are many people already doing this and making a huge profit by selling these restored radios. I bought one myself for $300.
